Alweld 1236 SS build

Post by erictetterton » 27 Feb 2015, 06:11

Alweld 1236 SS is a perfectly laid out boat for my needs. 0.080 all welded aluminum with a respectable sized front deck and open floor plan. Perfect for my solo fishing trips or bringing a buddy. I will use my SeaArk 1872 for big water adventures.


Well after waiting 3 months on my boat to be built, I finally got a call from A K Mccallum saying my boat was in. Here's a few pics of me bringing her home.


I made a trolling motor mount on the bow out of aluminum angle and starboard Image


I rebuilt a 2000 15hp Yamaha to go on it. The lower unit seals were bad so I had to replace them and a lot of other stuff. More pics to come soon

erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 27 Feb 2015, 08:14

Secured with toggle bolts so the 30# minnkota doesn't pull it off

I installed an all aluminum false floor (0.063) with closed cell foam inbetween the ribs for support. It came out very nicely.


erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 27 Feb 2015, 08:18

Made an electrical switch panel/FF holder


It has a LED light underneath to light up the floor at night


And a very bright 7" LED light bar for navigation


erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 27 Feb 2015, 08:21

I also made my own jack plate out of 1/4" aluminum angle and starboard


User avatar
gillhunter
Moderator
Posts: 1053
Joined: 10 Mar 2011, 11:47
Location: Winder, GA

Alweld 1236 SS build

Post by gillhunter » 27 Feb 2015, 08:31

Nice job. It should be a lot of fun to fish out of =D> =D>

User avatar
Knee Deep
Posts: 90
Joined: 07 Apr 2014, 20:21
Location: Crystal River, Fl.

Alweld 1236 SS build

Post by Knee Deep » 27 Feb 2015, 09:51

Nice build.
WeldCraft 1656 Tunnel, Yamaha F70, Garmin 547xs

erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 27 Feb 2015, 13:03

Thank you guys. It was a very simple build and it's going to allow me to catch a lot of fish in narrow places. More pics to come...

evidrine
Posts: 41
Joined: 23 Feb 2015, 09:35

Alweld 1236 SS build

Post by evidrine » 06 Mar 2015, 15:24

I really like that Jackplate. Awesome job.

erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 12 Mar 2015, 08:42

I'm welding on the pods

Last edited by erictetterton on 12 Mar 2015, 21:16, edited 2 times in total.

lckstckn2smknbrls
Posts: 4319
Joined: 05 Oct 2008, 12:14
Location: Algonquin Il

Alweld 1236 SS build

Post by lckstckn2smknbrls » 12 Mar 2015, 10:29

looks nice. Have you thought about changing the bow stop to a wide board, that V-bow stop puts excusive pressure on one small area.
1971 14' Ward's Sea King Jon Boat / 1983 Mariner 25HP

erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 12 Mar 2015, 14:32

Last edited by erictetterton on 12 Mar 2015, 21:07, edited 2 times in total.

evidrine
Posts: 41
Joined: 23 Feb 2015, 09:35

Alweld 1236 SS build

Post by evidrine » 12 Mar 2015, 15:06

Very nice. I wish I had the capabilities to add a set of pods to my current project. By the time I am done that's all I will be missing.

Stump Bumper
Posts: 25
Joined: 09 Mar 2015, 10:53

Alweld 1236 SS build

Post by Stump Bumper » 12 Mar 2015, 15:27

Hey Eric, nice looking Alweld. I was wondering if you've had your boat out yet and how the Lowrance worked with the transducer being mounted so close to the motor prop? I'm currently working on my 1544 Alumacraft and just had the pods welded on too. The link to my work in progress was just posted last night. I was contemplating a good mounting location for the transducer for my Lowrance Mark 4. If yours works well, I shouldn't have any problems.
Also, I'm in Farmville so if you're ever looking for a fishing buddy, let me know.

erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 12 Mar 2015, 21:11

Thanks. Stump bumper, it takes a lot of tweaking to get the transducer just right but it's definitely possible. I had a 1236 Alumacraft set up the same way as this boat and it worked great. I live in Winterville so im sure we fish the same waters. I bet u got modlins to weld yours on didn't you

erictetterton
Posts: 283
Joined: 22 Dec 2012, 00:56
Location: Winterville, NC

Alweld 1236 SS build

Post by erictetterton » 12 Mar 2015, 21:20

Here's the finished product. Note the trim tabs I welded on the bottom of the pods so the boat will ride level
